The Accu-Bend™ Rotary Bender transfers the vertical motion of the press into a smooth one-motion rotation. The smooth rotation provides a rotary bend process which requires less tonnage and less strain on the material. The Accu-Bend™ Rotary Bender can also include optional pre-configured mounting hole patterns. The saddle liner is a bronze alloy chosen for the ability to hold up to a bearing load with little to no wear while the graphite plugs are included in the bronze liner to provide lubrication. Both rockers and saddles are machined for precision. Compact benders fit in tight places and are ideal for bending small tabs within a larger part.
Accu-Bend™ Rotary Benders are available for simple or modified bends including 90° bends, square, over square, channel, hat bends, zee bends, short leg, under square, and "J" bends
| Brand | Lamina |
|---|---|
| Bender Type | Accu-Bend Standard |
| Rocker Diameter | 25 mm (0.98 in) |
| Bender Length | 300 mm (11.81in) |
| Saddle Width (E) | 75 mm (2.95in) |
| Minimum Part Height | 10 mm (0.39 in) |
| Saddle Height (A) | 30 mm (1.18 in) |
| Front Saddle (B) | 30 mm (1.18 in) |
| Load Capacity | 7920 KGS (17124.5 LBS) |
| Maximum Part Thickness | 2 mm (0.08 in) |
| Mounting Bold Size | M6 |
| Rocker Dimension (G) | 8.5 mm (0.33 in) |
| Saddle Thickness (D) | 38 mm (1.5 in) |
| Saddle to Key (C) | 45 mm (1.77 in) |
- Brand:
- Lamina
- Bender Type:
- Accu-Bend Standard
- Rocker Diameter:
- 25 mm (0.98 in)
- Bender Length:
- 300 mm (11.81in)
- Saddle Width (E):
- 75 mm (2.95in)
- Minimum Part Height:
- 10 mm (0.39 in)
- Saddle Height (A):
- 30 mm (1.18 in)
- Front Saddle (B):
- 30 mm (1.18 in)
- Load Capacity:
- 7920 KGS (17124.5 LBS)
- Maximum Part Thickness:
- 2 mm (0.08 in)
- Mounting Bold Size:
- M6
- Rocker Dimension (G):
- 8.5 mm (0.33 in)
- Saddle Thickness (D):
- 38 mm (1.5 in)
- Saddle to Key (C):
- 45 mm (1.77 in)
