Kit Components

NCD050506

SKC050012

CAM-ETCH

CAD files are for fitment purposes only. Radius run outs and transitions may be different in actual product.

image of catalog page

Brand Lamina
Face Height (mm) 95
Face Width (mm) 90
Stroke (mm) 45
Type Die Mount
Angle 5
Weight (lbs) 151.8000

CAD Data

CAD files are for fitment purposes only. Radius run outs and transitions may be different in actual product.

image of catalog page
